Arc Neodymium Magnet Neodymium magnet (NdFeB), commonly known as "rare earth" magnet, is a high-performance permanent magnet made of neodymium, iron and boron alloys. They are real permanent magnets and will not lose their magnetism unless heated to a temperature exceeding the maximum operating temperature rating or their protective coating is damaged. Characteristic: -Energy products may exceed 50mgoe -Low corrosion resistance Applications: -automotive -electronics (sensors, speakers, scanners) -medical (scanners) -magnetic separators
Block Neodymium Magnet 1.Dimensions: Customized / Produce according to your needs 2.Materials: NdFeB,Grade N35 to N52 (M,H,SH,UH,EH AH) 3.Plating/Coating: Nickel,Zinc,Epoxy and etc. 4.Magnetization direction: Through thickness,width,or length 5.Max operating temp.: 80 to 220 degrees celsius It can be very small block/cube,or it can be big block/bar and become a very powerful magnet.They are often used for industrial applications.
Laminated Magnet 1. Insulation layer thickness within 0.04mm. Insulation layers: 2-40 layers. 2. At normal temperature, the bonding strength of the insulation layer can reach more than 50Mpa. 3. The maximum operating temperature is 60-250 ℃. 4. Tolerance is within 0.05mm. 5. Each magnets are insulated from each other.
Laminated Magnet 1. Insulation layer thickness within 0.04mm. 2. At normal temperature, the bonding strength of the insulation layer can reach more than 50Mpa. 3. The maximum operating temperature can reach 200 ℃. 4. Tolerance is within 0.05mm. 5. Each magnets are insulated from each other.
Laminated Magnet 1. Insulation layer thickness within 0.04mm. 2. At normal temperature, the bonding strength of the insulation layer can reach more than 50Mpa. 3. The maximum operating temperature can reach 200 ℃. 4. Tolerance is within 0.05mm. 5. Each magnets are insulated from each other.
Laminated Magnet 1. Insulation layer thickness within 0.04mm. 2. At normal temperature, the bonding strength of the insulation layer can reach more than 50Mpa. 3. The maximum operating temperature can reach 200 ℃. 4. Tolerance is within 0.05mm. 5. Each magnets are insulated from each other.
Neodymium magnetic wheel/gear 1.Dimensions: Dia from 25mm to 160mm 2.Materials: NdFeB and Steel 3.Magnetization direction: Axial magnetized 4.Max operating temp.: 100 degrees celsius
Hard Anisotropic Ferrite Magnet 1.Dimensions: According to your requirements 2.Grade: Y30,Y30BH,Y30BH-1,Y35 and etc 3.Magnetized: Diametrical,Width,Thickness,as optional 4.Size:max out dia. 280mm,max thickness 40mm 5.Tolerance:OD and ID 2%,+/-0.1mm for thickness
Customized Permanent Ferrite Magnet/Ferrite Bar Magnets 1.Dimensions: According to your requirements 2.Grade: Y30,Y30BH,Y30BH-1,Y35 and etc 3.Magnetized: Length,Width,Thickness,as optional 4.Size:max out dia. 280mm,max thickness 40mm 5.Tolerance:OD and ID 2%,+/-0.1mm for thickness
Ferrite Ring Speaker Magnet/Large Ceramic Ring Magnets 1.Dimensions: According to your requirements 2.Grade: Y30,Y30BH,Y30BH-1,Y35 and etc 3.Magnetized: Diametrical,Axial,Thickness,as optional 4.Size:max out dia. 280mm,max thickness 40mm 5.Tolerance:OD and ID 2%,+/-0.1mm for thickness
Customized Ceramic Magnets /Magnet Ferrite Custom 1.Dimensions: According to your requirements 2.Grade: Y30,Y30BH,Y30BH-1,Y35 and etc 3.Magnetized: Diametrical,Axial,Thickness,as optional 4.Size:max out dia. 280mm,max thickness 40mm 5.Tolerance:OD and ID 2%,+/-0.1mm for thickness
Hard Anisotropic Ferrite Magnet Ceramic magnets (also known as "ferrite" magnets) are part of the permanent magnet family and are currently the lowest cost hard magnets. The ceramic (ferrite) magnet composed of strontium carbonate and iron oxide has medium strength and can be used at quite high temperature.
Hard Anisotropic Ferrite Magnet Ceramic magnets (also known as "ferrite" magnets) are part of the permanent magnet family and are currently the lowest cost hard magnets. The ceramic (ferrite) magnet composed of strontium carbonate and iron oxide has medium strength and can be used at quite high temperature.
Hard Anisotropic Ferrite Magnet Ceramic magnets (also known as "ferrite" magnets) are part of the permanent magnet family and are currently the lowest cost hard magnets. The ceramic (ferrite) magnet composed of strontium carbonate and iron oxide has medium strength and can be used at quite high temperature.
Hard Anisotropic Ferrite Magnet Ceramic magnets (also known as "ferrite" magnets) are part of the permanent magnet family and are currently the lowest cost hard magnets. The ceramic (ferrite) magnet composed of strontium carbonate and iron oxide has medium strength and can be used at quite high temperature.
